Phoenix Contact FL MGUARD RS4000 User Manual

FL MGUARD RS4000 TX/TX VPN-M
164
PHOENIX CONTACT 105656_en_05
7.10 Technical data
Hardware properties FL MGUARD RS4000 TX/TX VPN-M
Platform Freescale network processor with 330 MHz clocking
Network interfaces 1 LAN port | 1 WAN port
Ethernet IEEE 802.3 10/100-BaseTX
RJ45 | full duplex | auto MDIX
Other interfaces Serial RS-232 | D-SUB 9 connector
2 digital inputs and 2 digital outputs
Memory 128 MB RAM | 128 MB Flash | SD card
Replaceable configuration memory
Redundancy options Optional: VPN | router and firewall
Power supply Voltage range 11 ... 36 V DC, redundant
Power consumption 2.13 W, typical
Humidity range 5% ... 95% (operation, storage), non-condensing
Degree of protection IP20
Temperature range -40°C ... +70°C (operation)
-40°C ... +70°C (storage)
Dimensions (H x W x D) 130 x 45 x 114 mm (up to DIN rail support)
Weight 725 g (TX/TX)
Weight (incl. packaging) 900 g (TX/TX)
Firmware and power values FL MGUARD RS4000 TX/TX VPN-M
Firmware compatibility For mGuard v8.1.8 or later: Phoenix Contact recommends the use of the latest firm-
ware version and patch releases in each case.
For the scope of functions, please refer to the relevant firmware data sheet.
Data throughput (Firewall) Router mode, default firewall rules, bidirectional throughput: 120 Mbps, maximum
Stealth mode, default firewall rules, bidirectional throughput: 50 Mbps, maximum.
Virtual Private Network (VPN) IPsec (IETF standard)
Optionally up to 250 VPN tunnels
Hardware-based encryption DES | 3DES | AES-128/192/256
Data throughput encrypted (IPsec VPN) Router mode, default firewall rules, bidirectional throughput: 30 Mbps, maximum
Stealth mode, default firewall rules, bidirectional throughput: 20 Mbps, maximum
Management support Web GUI (HTTPS) | command line interface (SSH) | SNMP v1/2/3 | central device man-
agement software
Diagnostics LEDs (Power 1 + 2, State, Error, Signal, Fault, Modem, Info) signal contacts | service
contacts | log file | remote syslog
Other FL MGUARD RS4000 TX/TX VPN-M
Conformance CE | FCC | UL 508
ANSI/ISA 12.12 Class I Div. 2
Special features Realtime clock | Trusted Platform Module (TPM) | temperature sensor |
mGuard Remote Services Portal ready
