TC MGUARD RS4000/RS2000 4G
96
PHOENIX CONTACT 105656_en_05
4.10 Technical data
Hardware properties TC MGUARD RS4000 4G TC MGUARD RS2000 4G
Platform Freescale network processor Freescale network processor
Network interfaces 4 LAN Ports (managed) | 1 DMZ port |
1WAN port
Ethernet IEEE 802.3 10/100-BaseTX
RJ45 | full duplex | auto MDIX
4 LAN ports (unmanaged)
Ethernet IEEE 802.3 10/100-BaseTX
RJ45 | full duplex | auto MDIX
Wireless interface WAN | GSM | GPRS | EDGE | UMTS | CD-
MA2000
WAN | GSM | GPRS | EDGE | UMTS | CD-
MA2000
SIM interfaces (1 + 2) 1.8 V | 3 V, redundant 1.8 V | 3 V, redundant
Data rate ≤ 14.4 Mbps (HSDPA) ≤ 14.4 Mbps (HSDPA)
Other interfaces Serial RS-232 | D-SUB 9 connector
3 digital inputs and 3 digital outputs
Serial RS-232 | D-SUB 9 connector
3 digital inputs and 3 digital outputs
Memory 128 MB RAM | 128 MB Flash | SD card
Replaceable configuration memory
128 MB RAM | 128 MB Flash | SD card
Replaceable configuration memory
Redundancy options Optional: VPN | router and firewall –
Power supply Voltage range 11 ... 36 V DC, redundant Voltage range 11 ... 36 V DC, redundant
Power consumption typical < 200 mA (24 V DC) |
maximum < 800 mA (10 V DC)
typical < 200 mA (24 V DC) |
maximum < 800 mA (10 V DC)
Humidity range 5% ... 95% (operation, storage), non-con-
densing
5% ... 95% (operation, storage), non-con-
densing
Degree of protection IP20 IP20
Temperature range -40°C ... +60°C (operation)
-40°C ... +70°C (storage)
-40°C ... +60°C (operation)
-40°C ... +70°C (storage)
Vibration resistance in acc. with EN 60068-2-6/IEC 60068-2-6 5g, 10-150 Hz, 2.5 h, in XYZ direction 5g, 10-150 Hz, 2.5 h, in XYZ direction
Dimensions (H x W x D) 130 x 45 x 114 mm (up to DIN rail support) 130 x 45 x 114 mm (up to DIN rail support)
Weight 850 g 835 g
Firmware and power values TC MGUARD RS4000 4G TC MGUARD RS2000 4G
Firmware compatibility For mGuard v8.4.1 or later: Phoenix Contact recommends the use of the latest firm-
ware version and patch releases in each case.
For the scope of functions, please refer to the relevant firmware data sheet.
Data throughput (Firewall) Router mode, default firewall rules, bidirectional throughput: 110 Mbps, maximum
Stealth mode, default firewall rules, bidirectional throughput: 50 Mbps, maximum
When using the DMZ as independent network zone, the maximum possible data
throughput is distributed to the three zones.
Virtual Private Network (VPN) IPsec (IETF standard)
Optionally up to 250 VPN tunnels
IPsec (IETF standard)
Up to 2 VPN tunnels
Hardware-based encryption DES | 3DES | AES-128/192/256 DES | 3DES | AES-128/192/256
Data throughput encrypted (IPsec VPN) Router mode, default firewall rules, bidirectional throughput: 30 Mbps, maximum
Stealth mode, default firewall rules, bidirectional throughput: 20 Mbps, maximum
When using the DMZ as independent network zone, the maximum possible data
throughput is distributed to the three zones.
Data throughput (mobile) Depending on the mobile connection
≤ 50 Mbit/s (LTE) upload
≤ 150 Mbit/s (LTE) download
Management support Web GUI (HTTPS) | command line interface (SSH) | SNMP v1/2/3 | central device man-
agement software
Diagnostics 13 LEDs (Power 1 + 2, State, Error, Signal, Fault, Modem, Info, Signal Status, SIM Sta-
tus) | Service I/O| Log File | Remote Syslog
