FL MGUARD GT/GT
192
PHOENIX CONTACT 105656_en_05
8.9 Technical data
General data FL MGUARD GT/GT
Function Security applicance, firewall, routing, 1:1 NAT; VPN (optional), conforms to
standard IEEE 802.3/802.3u/802.3ab
Firewall principle Stateful inspection
SNMP Version 2c, 3
Data throughput (Firewall) Router mode, default firewall rules, bidirectional throughput: max. 350 Mbps
Stealth mode, default firewall rules, bidirectional throughput: max. 120 Mbps
Hardware-based encryption DES | 3DES | AES-128/192/256
Data throughput encrypted (IPsec VPN) Router mode, default firewall rules, bidirectional throughput: max. 110 Mbps
Stealth mode, default firewall rules, bidirectional throughput: max. 60 Mbps
Management support Web GUI (HTTPS) | command line interface (SSH) | SNMP v1/2/3 |central de-
vice management software | optional key switch (VPN)
Housing dimensions (width x height x depth) in mm 128 x 110 x 69 (depth from top edge of DIN rail)
128 x 150 x 69 (depth from top edge of DIN rail)
with FL MEM PLUG (accessories)
Permissible operating temperature -20°C ... 60°C
Permissible storage temperature -40°C ... +85°C
Degree of protection IP20, IEC 60529
Protection class Class 3 VDE 0106; IEC 60536
Humidity
Operation 5% ... 95%, non-condensing
Storage 5% ... 95%, non-condensing
Air pressure
Operation 86 kPa ... 108 kPa, 1500 m above sea level
Storage 66 kPa ... 108 kPa, 3500 m above sea level
Ambient compatibility Free from substances that would hinder coating with paint or varnish accord-
ing to VW specification
Mounting position Perpendicular to a standard DIN rail
Connection to protective earth ground By snapping onto a grounded DIN rail
Weight 660 g, typical
Supply voltage (US1/US2 redundant) FL MGUARD GT/GT
Connection Via plug-in screw terminal block; max. conductor cross section = 2.5 mm²
Nominal value 24 V DC
Permissible voltage range 18.0 V DC to 32.0 V DC
Permissible ripple (within the permissible voltage range) 3.6 V
PP
Test voltage 500 V DC for one minute
Current consumption on US at 24 V DC, maximum 270 mA
Maximum power consumption at nominal voltage 6.5 W
Interfaces FL MGUARD GT/GT
Number of Ethernet ports 2, should be operated as RJ45 port or SFP port
RS-232 configuration interface
Connection format Mini-DIN socket
