TC MGUARD RS4000/RS2000 4G
92
PHOENIX CONTACT 105656_en_05
4.9 Restart, recovery procedure, and flashing the firm-
ware
The Reset button is used to set the device to one of the following states:
– Performing a restart
– Performing a recovery procedure
– Flashing the firmware/rescue procedure
Figure 4-9 Reset button
4.9.1 Performing a restart
Objective The device is restarted with the configured settings.
Action • Press the Reset button for around 1.5 seconds until the Err LED lights up.
(Alternatively, disconnect the power supply and then connect it again.)
