FL MGUARD RS4000/RS2000
105656_en_05 PHOENIX CONTACT 33
1.10 Technical data
Hardware properties FL MGUARD RS4000 FL MGUARD RS2000
Platform Freescale network processor with
330 MHz clocking
Freescale network processor with
330 MHz clocking
Network interfaces 1 LAN port | 1 WAN port
Ethernet IEEE 802.3 10/100-BaseTX
RJ45 | full duplex | auto MDIX
1 LAN port | 1 WAN port
Ethernet IEEE 802.3 10/100-BaseTX
RJ45 | full duplex | auto MDIX
Other interfaces Serial RS-232 | D-SUB 9 connector
2 digital inputs and 2 digital outputs
Serial RS-232 | D-SUB 9 connector
2 digital inputs and 2 digital outputs
Memory 128 MB RAM | 128 MB Flash | SD card
Replaceable configuration memory
128 MB RAM | 128 MB Flash | SD card
Replaceable configuration memory
Redundancy options Optional: VPN | router and firewall Not available
Power supply Voltage range 11 ... 36 V DC, redundant Voltage range 11 ... 36 V DC
Power consumption 2.13 W, typical 2.13 W, typical
Humidity range 5% ... 95% (operation, storage), non-con-
densing
5% ... 95% (operation, storage), non-con-
densing
Degree of protection IP20 IP20
Temperature range -20°C ... +60°C (operation)
-20°C ... +60°C (storage)
-20°C ... +60°C (operation)
-20°C ... +60°C (storage)
Dimensions (H x W x D) 130 x 45 x 114 mm (up to DIN rail support) 130 x 45 x 114 mm (up to DIN rail support)
Weight 725 g (TX/TX) 725 g (TX/TX)
Weight (incl. packaging) 900 g (TX/TX) 900 g (TX/TX)
Firmware and power values FL MGUARD RS4000 FL MGUARD RS2000
Firmware compatibility For mGuard v7.4.0 or later: Phoenix Contact recommends the use of the latest firm-
ware version and patch releases in each case.
For the scope of functions, please refer to the relevant firmware data sheet.
Data throughput (Firewall) Router mode, default firewall rules, bidirectional throughput: 120 Mbps, maximum
Stealth mode, default firewall rules, bidirectional throughput: 50 Mbps, maximum.
Virtual Private Network (VPN) IPsec (IETF standard)
Optionally up to 250 VPN tunnels
IPsec (IETF standard)
Up to 2 VPN tunnels
Hardware-based encryption DES | 3DES | AES-128/192/256 DES | 3DES | AES-128/192/256
Data throughput encrypted (IPsec VPN) Router mode, default firewall rules, bidirectional throughput: 30 Mbps, maximum
Stealth mode, default firewall rules, bidirectional throughput: 20 Mbps, maximum
Management support Web GUI (HTTPS) | command line interface (SSH) | SNMP v1/2/3 | central device man-
agement software
Diagnostics LEDs (Power 1 + 2, State, Error, Signal,
Fault, Modem, Info) signal contacts | ser-
vice contacts | log file | remote syslog
LEDs (Power, State, Error, Signal, Fault,
Modem, Info) signal contacts | service
contacts | log file | remote syslog
Other FL MGUARD RS4000 FL MGUARD RS2000
Conformance CE | FCC | UL 508
ANSI/ISA 12.12 Class I Div. 2
Special features Realtime clock | Trusted Platform Module (TPM) | temperature sensor |
mGuard Remote Services Portal ready
