FL MGUARD SMART2
224
PHOENIX CONTACT 105656_en_05
10.8 Restart, recovery procedure, and flashing the firm-
ware
The Reset button is used to set the device to one of the following states:
– Performing a restart
– Performing a recovery procedure
– Flashing the firmware/rescue procedure
Figure 10-5 Reset button
10.8.1 Performing a restart
Objective The device is restarted with the configured settings.
Action • Press the Reset button for around 1.5 seconds until the middle LED lights up in red.
(Alternatively, you can disconnect and insert the USB cable, as it is only used for the
power supply.)
Reset button
(Located in the opening.
Can be pressed with a
straightened paper clip,
for example.)
