FL MGUARD GT/GT
182
PHOENIX CONTACT 105656_en_05
8.4.3 Configuration in Router mode
To access the configuration interface, it may be necessary to adapt the network configura-
tion of your computer.
Under Windows 7, proceed as follows:
• In the Control Panel, open the “Network and Sharing Center”.
• Click on “LAN connection”. (The “LAN connection” item is only displayed if a connection
exists from the LAN interface on the computer to a mGuard device in operation or an-
other partner).
• Click on “Properties”.
• Select the menu item “Internet protocol Version 4 (TCP/IPv4)”.
• Click on “Properties”.
• First select “Use the following IP address” under “Internet Protocol Version 4 Proper-
ties”, then enter the following address, for example:
By default upon delivery, following reset to the default settings or after flashing the device,
the device can be accessed within the network 192.168.1.0/24 via the LAN interface un-
der IP address 192.168.1.1.
IP address: 192.168.1.2
Subnet mask: 255.255.255.0
Default gateway: 192.168.1.1
Depending on the configuration of the device, it may then be necessary to adapt the net-
work interface of the locally connected computer or network accordingly.
