FL MGUARD RS4004/RS2005
105656_en_05 PHOENIX CONTACT 37
Info2 Green On The configured VPN connections are established at output O1 or the firewall re-
cords defined at output O1 are activated.
Flashing The configured VPN connections are being established or aborted at output O1 or
the firewall rule records defined at output O1 are activated or deactivated.
Info1 Green On The configured VPN connections are established at output O2 or the firewall re-
cords defined at output O2 are activated.
Flashing The configured VPN connections are being established or aborted at output O2 or
the firewall rule records defined at output O2 are activated or deactivated.
WAN 1 Green On The LEDs are located in the sockets (10/100 and duplex LED)
Ethernet status. The LEDs indicate the status of the relevant port. As soon as the
device is connected to the relevant network, a continuous light indicates that there
is a connection to the network partner in the LAN, WAN or DMZ. When data pack-
ets are transmitted, the LED goes out briefly.
DMZ1
1
Green On
LAN 1–4/5
2
Green On
1
FL MGUARD RS4004 only
2
FL MGUARD RS2005 only
Table 2-2 LEDs on the FL MGUARD RS4004 and FL MGUARD RS2005 [...]
LED State Meaning
