48 PianoDisc Installation Guide
228CFX - PianoCD - iQ
The bracket should be positioned so that the mounting
screws are approximately in the middle of the slot. This
leaves room for a small final adjustment. Mount two
brackets on each rail.
Figure 32
Step 25: Install the solenoid rail
A. PianoDisc has available “stud locators” which can be used to locate the
hanger stud.
Figure 33
