70 PianoDisc Installation Guide
228CFX - PianoCD - iQ
Power Up
During power up, the iQ system runs a system check to search for Driver CPU
software version J or higher and a saved Learn table. This may take a few
seconds. Depending on what the system found, you’ll see one of the
following:
What you see What does it mean
Status LED illuminates amber A Learn table was found. The iQ system is
ready for configuration or music playback.
Status LED illuminates red A Learn table was not found. The piano
must be learned before attempting music
playback.
(For Wireless Systems)
Status
LED illuminates red
Select LEDs illuminate yellow (for one
second)
Status LED turns amber
A Learn table was found.
The system is ready for configuration or
music playback.
(For Wireless Systems)
Status
LED illuminates red
Select LEDs illuminate yellow (for one
second)
Status LED remains red
A Learn table was not found. Learn the
piano before attempting music playback.
• Use the appropriate cable to connect iQ to the
Driver CPU. Disconnect when the learn is
complete and reinstate the wireless setup.
(For a Wired System)
Status
LED illuminates red,
Select LEDs illuminate yellow (for one
second)
Status LED remains red
This indicates one of the following:
• Cable connections are not secure. Check and
secure the cable connections between iQ and
the Driver CPU.
• The Driver CPU software version may be earlier
than I. Update the software before you continue
with system setup.
• The Driver CPU isn’t working properly. Call
PianoDisc Technical Support.
