PianoDisc Installation Guide 73
. . . . .
Pedal Adjust Mode
After learning the piano, give the pedal solenoid the necessary amount of
power needed to strike and hold the pedal.
IMPORTANT: See the
Technical Information Guide: SilentDrive System
to learn more
about why pedal adjustments are necessary and how to quantify adjustment values.
To select the Pedal Adjust mode:
1. Rotate the Select wheel (+) or (-) until the Learn LED is illuminated.
• The Status LED remains dark.
2. Push in and hold the Select wheel for approximately two seconds.
•The Learn LED flashes steadily.
• After two seconds, the Status LED illuminates (green).
3. Release the Select wheel.
• The pedal starts to rise and fall.
• The initial pedal hold value is 0 and strike value is 50.
4. You are now ready to raise or lower the pedal strike value.
To increase or decrease the Pedal Strike value:
1. Rotate the Select wheel (+) to increase the value or (-) to lower the value:
•Hold
the wheel in this position to adjust the pedal strike over several increments at a
time.
OR
• Rotate and release to adjust the pedal strike by increments of 5.
2. After the
Pedal Strike Value
is adjusted, change the
Pedal Hold
adjustment:
• Push in and release the Select wheel.
•The Learn LED double flashes. An initial hold value of 30 has been set.
