Planet IMG-2100T - 2 Installation; Hardware Description; Physical Dimensions

User’s Manual of IMG-2x00T Modbus Gateway Series
15
2. INSTALLATION
This section describes the hardware features and installation of the Modbus Gateway' components on the desktop or rack. For
easier management and control of the Modbus Gateway, familiarize yourself with its display indicators, and ports. Front panel
illustrations in this chapter display the LED indicators. Before connecting any network device to the Modbus Gateway, please
read this chapter completely.
2.1 Hardware Description
2.1.1 Physical Dimensions
 IMG-2100T: 32 x 87 x 135 mm (W x D x H)
