User’s Manual of IMG-2x00T Modbus Gateway Series
4.6 SNMP Setup
Use the Port Menu to display or configure the Modbus Gateway's ports. This section includes the page that displays current port
configurations. Ports can also be configured here. The Port Configuration screen in Figure 4-6-1 appears.
Figure 4-6-1: SNMP Setup page Screenshot
The page includes the following fields:
Object Description
• SNMP Active
Indicates the SNMP mode operation. Possible modes are:
Disable: Disable SNMP mode operation.
Enable: Enable SNMP mode operation.
• Community
Indicates the security name to map the community to the SNMP Groups
configuration.
• Contact
The textual identification of the contact person for this managed node, together
with information on how to contact this person.
• Location
The physical location of this node (e.g., telephone closet, 3rd floor).
• Trap Server
Indicates the SNMP trap destination address. It allows a valid IP address or
domain name.
Events
Object Description
• Cold Start Trap
This event is triggered when the power is interrupted and restarted.
• Warm Start Trap
This event occurs when the device is reset but does not turn off the power.
• Authentication Failure
Trap
This event occurs when an incorrect or unauthorized password are entered.
