User’s Manual of IMG-2x00T Modbus Gateway Series
4.2 System
Use the System menu items to display and configure basic administrative details of the Modbus Gateway. Under the System,
the following topics are provided to configure and view the system information. This section has the following items:
System The Modbus Gateway system information is provided here.
Port
This page displays status of each port.
Device Configure device name and syslog server on this page.
Time
Configure NTP server or manually adjust time on this page.
Console
Email
Configure management methods on this page.
Set up the SMTP mail parameters for further operation of events.
4.2.1 System
The System page provides basic information for the current device. System page helps an administrator to identify software
version, system uptime and IP address information. The screen in Figure 4-2-1 appears.
Figure 4-2-1: System Status Page Screenshot
The page includes the following fields:
Device Information
Object Description
• Model
Specifies the device model name.
• Firmware Version
The firmware version of Modbus Gateway.
• Server Name
The system name configured in Basic/Device Name.
• Current Time
The current (GMT) system time and date.
• System Up Time
The period of time the device has been operational.
