User’s Manual of IMG-2x00T Modbus Gateway Series
3.2 Web Management
The Modbus Gateway offers management features that allow users to manage the Modbus Gateway from anywhere on the
network through a standard browser such as Microsoft Internet Explorer. After you set up your IP address for the switch, you can
access the Modbus Gateway's Web interface applications directly in your Web browser by entering the IP address of the
Modbus Gateway.
For example, the default IP address of the Modbus Gateway is 192.168.0.100, then the manager PC should be set to
192.168.0.x (where x is a number between 1 and 254, except 100), and the default subnet mask is 255.255.255.0.
Figure 3-2-1: Web Management
You can then use your Web browser to list and manage the Modbus Gateway configuration parameters from one central
location, just as if you were directly connected to the Modbus Gateway's console port. Web Management requires either
Microsoft Internet Explorer 7.0 or later, Safari or Mozilla Firefox 1.5 or later.
3.2.1 Logging in to the Modbus Gateway
1. Use Internet Explorer 8.0 or above for Web browser and enter IP address http://192.168.0.100 (the factory default IP
address) to access the Web interface.
2. When the following dialog box appears, please enter the default user name “admin” and password “admin” (or the
password you have changed before) as shown in Figure 3-2-2.
Default IP Address: 192.168.0.100
Default User Name: admin
Default Password: admin
