Planmeca Proline XC - Page 44

Chapter C - HELP & ERROR MESSAGES
C-2 Planmeca Proline XC X-ray unit
ERROR MESSAGES
Technical Manual
Er 08
The wrong type sensor head (i.e. panoramic type) attached to the cephalostat.
Er 10
Overvoltage in tube head.
Er 11
Sudden kilovolt drop.
Er 12
Tube filament initializing is not done.
Er 21
Up/down motor time out. The vertical carriage does not reach the limit sensor
within a specified time.
Er 22
Temple support motor time out.
Er 23
Layer adjust motor time out. The layer mechanism does not reach the limit sensor
within a specified time.
Er 24
Primary collimator motor time out. The collimator mechanism does not reach the
sensor in specified time.
Er 25
Cassette motor time out. The cassette holder mechanism does not reach the limit
sensor within a specified time.
Er 26
Rotation motor time out. The rotating unit does not reach the limit sensor in the
specified time.
Er 27
Cephalostat scanning mechanism time out.
Er 28
Panoramic sensor head motor time out. The sensor head does not reach the pan-
oramic position in the specified time. Or the safety limit switch is pressed and the
movement of the sensor head is prevented.
Er 30
kV value does not reach given value.
Er 31
mA value does not reach given value.
Er 32
Tube filament control inoperative.
Er 33
Tube filament control inoperative.
Er 40
The rotation does not reach the end limit sensor.
Er 41
Rotation goes over the end limit sensor.
Er 42
Secondary collimator not in the position for the panoramic exposure.
Er 43
Secondary collimator not in the position for the cephalometric exposure.
Er 44
The patient positioning mechanism zero point set incorrectly.
Er 50
The temperature of the tube head is too low.
Er 51
Temperature sensor open.
Er 52
mA or kV feedback cable open.
Er 53
Up/down motor does not consume power.
Er 54
Up/down motor consumes too much power.
ERROR CODE ERROR MESSAGE EXPLANATION
