8 SYSTEM DESCRIPTION
User’s & installation manual Planmeca ProScanner 13
8 SYSTEM DESCRIPTION
The Planmeca ProScanner systems consists of
a scanner, Planmeca Romexis computer, and
an optional Planmeca ProID RFID reader. The
scanner can be connected to the computer via
Ethernet or USB cable.
NOTE
N-to-N Ethernet mode and 1-to-1 Ethernet mode
cannot be used in the same network at the same
time.
8.1 USB or direct 1-to-1 Ethernet
Planmeca ProScanner is attached to the PC
using direct USB or Ethernet connection.
Crossed Ethernet cable must be used.
USB cable Max. 2m
100 - 240 VAC
Romexis PC
Planmeca
ProScanner
Ethernet cable Max. 2m
CAT.5E, RJ45 FTP Cross Type Cable
