7 UNPACKING PLANMECA PROSCANNER
User’s & installation manual Planmeca ProScanner 11
7 UNPACKING PLANMECA PROSCANNER
Planmeca ProScanner is shipped in a custom
designed container to protect the scanner from
external shock. Before unpacking the scanner,
inspect the shipping container for damage. In
case the container is damaged, notify the
shipper immediately.
To unpack the scanner:
1. Carefully remove the contents from the box.
The imaging plates are on top of the package.
Handle them with care.
2. Check that all listed items are included in the
delivery.
3. Store the delivery box for possible later use.
The scanner must always be shipped in the
original delivery box.
7.1 Package contents
• Planmeca ProScanner
• Power adapter
AC/DC Adapter
Manufacturer: Bridge Power corp.
Model: BPM050X24XXX
This adapter meets the requirements of
IEC60601-1.
• USB 2.0 interface cable
• RJ45 CAT.5E FTP cable 2M (Cross type)
• Power Cord
Type SJT or SVT, min. 18AWG, 3-Conductor,
VW-1 125V, min 10A (or 250V, 10A). Max 3.0m
long; one end with Hospital Grade Type, NEMA
5-15P for 125V or NEMA 6-15P for 250V, other
end with appliance coupler.
Grounding reliability can only be achieved
when the equipment is connected to an
equipment receptacle marked “Hospital
Only” or “Hospital Grade”.
