Plockmatic BK5030 - Book Folder; Clearing Misfeed(S); Inside the Book Folder; Exit Area

5
44
Open the top cover.
Lift up both upper feed belts (A).
Note
Press the green dots (B) on the latches to release.
Remove the misfeeds.
Place the upper feed belts in normal position.
Close the top cover.
Inside the Book Folder
Exit area
Open the top cover.
Remove the misfeeds through the jam clearance
area (A).
Close the top cover.
A
Clearing misfeed(s)
Book Folder
B
B
A
