Plockmatic BK5030 - System Set Size Guide

8
60
Paper size
<A3 (small sizes) >A3 (large sizes)
Grain direction Grain direction
Short Long Short Long
Area coverage Area coverage Area coverage Area coverage
Paper weight
Low High Full Low High Full Low High Full Low High Full
Bond Offset Cover Tag Index Gsm
20 50 28 46 42 80 30 25 22 27 22 20 27 22 20 24 17 14
24 60 33 56 50 90 26 23 21 24 20 18 24 20 18 21 17 14
28 70 39 64 58 100 24 21 19 21 19 17 21 19 17 19 16 14
29 73 40 62 60 110 17 17 17 17 17 16 17 17 16 17 16 13
31 81 45 73 66 120 17 17 17 17 16 15 17 16 15 15 15 13
35 90 48 80 74 130 17 17 16 16 15 14 16 15 14 14 13 12
36 90 50 82 75 140 17 16 14 15 14 13 15 14 13 13 12 11
39 100 54 90 81 150 15 15 13 14 13 12 14 13 12 12 11 10
43 110 60 100 90 160 12 12 12 12 12 11 12 12 11 11 11 9
44 110 61 102 92 170 12 12 12 12 11 10 12 11 10 10 10 9
47 120 65 108 97 180 12 12 11 11 10 10 11 10 10 10 9 8
190 12 11 10 10 10 9 10 10 9 9 9 8
53 135 74 122 110 200 11 10 10 10 9 8 10 9 8 9 8 7
54 137 75 125 113 210 10 10 9 9 9 8 9 9 8 8 8 7
58 146 80 134 120 220 9 9 9 9 8 8 9 8 8 8 7 6
230 9 9 8 8 8 7 8 8 7 7 7 6
65 165 90 150 135 240 9 8 8 8 7 7 8 7 7 7 7 6
67 170 93 156 140 250 8 8 7 7 7 6 7 7 6 7 6 5
260 6 6 6 6 6 6 6 6 6 6 6 5
72 183 100 166 150 270 6 6 6 6 6 6 6 6 6 6 6 5
76 192 105 175 158 280 6 6 6 6 6 5 6 6 6 6 5 5
290 6 6 5 5 5 4 6 6 5 5 5 4
300 6 5 4 5 4 4 6 5 4 5 4 4
BK5030 System Set Size Guide
Note
1. For cover jobs , deduct 2 sheets
2. Paper size: large = A3> , Small = <A3
3. Area coverage: Low = text only, High = Pictures, Full = Maximum coverage
4. For jobs with multiple sheets of 200 gsm or higher paper weight the BF5030 module is
recommended for an acceptable output
