Booklet maker fault codes
Check stapler or Change staple cartridge
These messages will be displayed when a staple cartridge is empty or when stapling could
not be performed. Check in the following order:
– If a staple cartridge is empty, replace according to section 1. Basics.
– If staple cartridges are OK; remove the set and check that the number of sheets is within
specications.
– If staple cartridges are OK and set is within specications; remove and check stapler head
according to section 1. Basics.
Set too thick
This message will be displayed when the set sent from the copier is outside Booklet Maker
specications. Open the top cover, remove the set and close the top cover.
Remove purged sets
This message will be displayed when the purged set is in the infeed area. Open the top cover,
remove the set and close the top cover.
Illegal feed mode
If this message is displayed, contact customer support.
Stacker full
This message will be displayed when the Stacker is full. Empty Stacker.
Double feed
This message will be displayed when the Cover Feeder detects that more than one cover
was fed from the cover bin. If more than one cover was fed, check cover loading according to
section 2. Making Booklets. If the covers that are fed are thick, with dark print or with mixed
prints on the covers, double feeding may be displayed even if that is not the case. Turn off
double sheet detection according to section 3. Tools.
Misfeed
This message will be displayed when the Cover feeder could not feed a cover from the paper
bin. Check cover loading according to section 2. Making Booklets. If problem persists, clean
separator pad according to section 7. REMARKS.
Cover feeder fault codes
Continued on next page.
