Plockmatic BK5030 - Cover Feeder CF5030 (Option); Trimmer TR5030 (Option)

8
58
Cover Feeder CF5030 (option)
Specications Remarks
Maximum Speed Same as BK5030 A3/11x17” or bigger paper
sizes, need two sheet sets as
inlet at least
Standard Paper Sizes Same as BK5030
Paper Weight (Minimum) 70 gsm / 18 lb Bond
Paper Weight (Maximum) 250 gsm / 67 lb Bond
Cover Feeder Capacity 20 mm (app. 200 sheets of 80 gsm paper)
13/16” (app. 200 sheets of 20 lb Bond paper)
Off-line Use Possible (Together with Booklet maker)
Weight 7 kg / 15.4 lb or less
Dimensions (L x H x D) 310 x 190 x 530 mm / 12.2 x 7.5 x 20.9” The Cover Feeder dimensions
are included in the Booklet
Maker diversions and will not
add anything more to the space.
Power Source From BK5030
Trimmer TR5030 (option)
Specications Remarks
Speed 1800 sets per hour
Standard Paper Sizes Same as BK5030 Custom sizes are available
Default trim length 4.5 mm / (11/64”) Adjustable in 0.5 mm steps
Minimum trimming 1 mm / (0.0394 in)* Adjustable in 0.5 mm steps
Maximum trimming 16 mm (0.63”) Adjustable in 0.5 mm steps
Paper Weight (Minimum) Same as BK5030
Paper Weight (Maximum) Same as BK5030 Engine Duplex: 216 gsm
Input / Output Sheets Same as BK5030
Off-line Use Possible (Together with Booklet maker)
Weight 70 kg / 154.3 lb or less
Dimensions (L x H x D) 360 x 1010 x 620 mm / 14.2 x 39.8 x 24.4”
Power Source From BK5030
* When trimming SRA3 (450 mm) Booklets minimum trimming is 5 mm, when trimming 18” Booklets mini-
mum trimming is 9 mm.
