PH-2 SERVICE MANUAL
15. PARTS IDENTIFICATION
PH-2 (LOW PRESSURE)
ITEM QTY PART NUMBER DESCRIPTION
1 32 202191 BHCS, #8-32 X 0.250, 18-8 SS
2 2 201057 NUT, HEX, #8-32, 18-8 SS
3 22 201060 WASHER, LOCK, 1/4, 18-8 SS
4 1 201242 LIGHT UNIT, RED, 120VAC
5 1 201243 LIGHT UNIT, WHITE, 120VAC
6 4 201529 FHCS, 1/4-20 X 0.750, 18-8 SS
7 4 201580 WASHER, FLAT, 5/16, 18-8 SS
8 4 201581 HHCS, 1/4-20 X 0.750, 18-8 SS
9 2 201586 SHCS, #8-32 X 1.75, 18-8 SS
10 18 201621 WASHER, FLAT, 1/4, 18-8 SS
11 10 201627 WASHER, FLAT, 3/8, 18-8 SS
12 10 201628 WASHER, LOCK, 1/8, 18-8 SS
13 8 201899 BHCS, 1/4-20 X 0.750, 18-8 SS
14 26 201930 HHCS, 1/4-20 X 1.000, ZP GRD8
15 4 202145 WASHER, LOCK, 5/16, 18-8 SS
16 6 202152 HHCS, 3/8-16 X 1.000, ZP GRD8
17 1 202200 BHCS, #8-32 X 0.750, 18-8 SS
18 4 202200 BHCS, #8-32 X 0.750, 18-8 SS
19 4 202202 BHCS, #10-24 X 0.3125, 18-8 SS
20 4 202203 SHCS, #10-24 X 2.000, 18-8 SS
21 4 202151 HHCS, 5/16-18 X 1.000, ZP GRD8
22 4 201940 BHCS, 3/8-16 X 2.250, 18-8 SS
23 1 CL-03004 HEATER COVER TOP
24 1 CL-03005 HEATER COVER FRONT
25 2 CL-03006 HEATER COVER ENDS
26 1 CL-03007 THERMOCOUPLE COVER
27 1 CL-03008 HEATER HOLE COVER 1
28 2 CL-03009 HEATER HOLE COVER 2
29 4 EL-00052 SOLENOID VALVE CONNECTOR
30 4 EL-00053 SOLENOID VALVE GASKET
31 1 EL-00118A-00-1 HOSE BREAKER MOUNTING PLATE
32 2 EL-05220-01 CONSOLE KNOBS
33 1 EL-05226 120V TRANSFORMER
34 1 EL-05230-03 RT ANGLE CONDUIT CONNECTOR
35 1 EL-05237 THERMOCOUPLE HARNESS
36 1 EL-150 CIRCUIT BREAKER 63AMP
37 4 EL-158 MICRO CORDSET 90 DEGREE
38 1 EL-192 TERMINAL BLOCK
39 1 EL-193 INRUSH CURRENT LIMITER
40 2 EL-195 0-5000 PRESS TRANSDUCER
