POLYURETHANE
MACHINERY
CORPORATION
PH-2 SERVICE MANUAL
15. PARTS IDENTIFICATION
ITEM QTY PART NUMBER DESCRIPTION
41 1 EL-202-SIZE CONSOLE ASSEMBLY
42 1 EL-35 HOSE HEAT RELAY
43 1 EL-35-1 HEAT SINK
44 1 EL-37 TRANSFORMER, SIGNAL
45 2 EL-42-2200 PRESSURE SWITCH
46 1 FR-10 FRAME ASSY, PH-2
47 1 HI-05003 DIRECTIONAL VALVE
48 4 HI-05011 6 ORB X 6 JIC
49 2 HI-05028 PRESSURE GAUGE 0-3000 PSI
50 2 HI-05304 HYD CYLINDER TUBE
51 1 HI-05331 EXIT MANIFOLD ASSY
52 1 HI-05335 HYDRAULIC MANIFOLD ASSY
53 2 HI-05347 3/8 NPT X 6 JIC 90 DEGREE
54 2 HI-05351 PRESSURE MANIFOLD
55 2 HOSE HEAT WIRE HOSE HEAT WIRE
56 2 KT-00029A-1 HOSE HEAT, CONNECTOR BODY
57 2 KT-05005 INLET MONITORING KIT
58
1 ML-1 MOTORLINE ASSY 18CC, 3HP, 3PH
1 ML-2 MOTORLINE ASSY 18CC, 3HP, 1PH
59 1 MQ-01009-01A LUBE BOTTLE
60 1 MQ-01009-02A LUBE BOTTLE LID
61
1 PH-21 PREHEATER ASSY, 3.75KW
1 PH-22 PREHEATER ASSY, 4.5KW
1 PH-23 PREHEATER ASSY, 5.25KW
61
1 PH-33 8 ROD HEATER ASSY, 7 KW
62 1 PL-9 PUMP-LINE, PH-2
63 2 PU-07000 CLEAR PUMP COVER
64 1 RA-00066A CBMB 90 DEG MALE ELBOW NPT
65 1 RA-00067A CBMB 90 DEG MALE ELBOW NPT
66 1 RA-00068A CHECK VALVE
67 1 RA-06008 CHECK VALVE, POLYTUBE, 3/8
68 1 RM-05201-2 CONSOLE ENCLOSURE, TOP
69 1 RM-212 TRANSFORMER DOOR
70 1 RM-222 TRANSFORMER BRACKET
71 2 RM-243 PROX SENSOR MOUNTING ASSY
72 1 TN-04196 HOSE CLAMP
73 1 YS-1 Y-STRAINER ASSY ”A” SIDE
74 1 YS-2 Y-STRAINER ASSY ”R” SIDE
REVISION 1.2 81
