ELECTRICAL
10.8
Characteristic MIN TYP MAX UNIT Note
STARTER Output
Current 6 Amp Current capability of the STARTER output
TRANS
Neutral Voltage 4.5 -- 16 Vdc
BRAKE On
Input Voltage 2 14 16 Vdc Voltage on BRAKE input to activate the STARTER
output
REVERSE POLARITY PROTECTION
Battery Reverse Current 1.8 2 mA Max reverse leakage current when connected in
reverse
Reverse Bias Voltage -- 55 Vdc Absolute maximum reverse voltage before device
breakdown
TEMPERATURE CONTROLLER
Open Thermistor
Resistance
50k ohm Above this resistance is assumed to be an open
thermistor , causing the FAN and HOT indicator to
activate
Fan OFF Resistance 3362 3466 3570 ohm Thermistor resistance above this value will turn off
the fan
Fan ON Resistance 2426 2519 2612 ohm Thermistor resistance below this value will turn on
the fan
Engine Temperature In-
dicator ON Resistance
1534 1607 1680 ohm Thermistor resistance below this value will cause
the HOT indicator output to pull low
Engine Temperature In-
dicator OFF Resistance
1534 1607 1680 ohm Thermistor resistances above this value will not
activate the HOT inidicator output
