4.24

ELECTRONIC FUEL INJECTION

Fuel Tank Removal (RZR / RZR S)

IMPORTANT: Syphon as much fuel from the tank as

possible before attempting to remove it from the

vehicle.

1. Remove the driver and passenger seats along with the rear

service panel.

2. Disconnect the negative battery cable from the battery

located under the driver’s seat.

3. While holding a shop towel over the fuel line connector,

disconnect the quick connect fuel line from the fuel pump.

Move the fuel line out of the way for tank removal.

NOTE: A small amount of fuel may come out of the

fuel line or tank. Properly drain fuel into a suitable

container.

4. Disconnect the fuel pump electrical harness.

5. Remove the fuel tank vent hose clamp with a suitable pliers

and remove the vent line from the tank vent fitting.

6. Remove the rear seat base assembly from the vehicle by

removing the (2) fasteners retaining the rear seat base.

7. Remove the shift knob and center console from the vehicle.

8. Remove the push rivets and screws retaining the RH rocker

panel and remove panel from the vehicle (see Chapter 5).

WARNING

Always wear safety goggles when working with

high pressure or flammable fluids. Failure to do so

could result in serious injury or complications.

Disconnect

Here

Remove

RH Rocker Panel
