10.20
ELECTRICAL
FUSE BOX: FUSES / RELAYS / CIRCUIT BREAKER
Overview / Operation
Located in the fuse box under the dash, the fuses provide overload protection for wiring and components such as the instrument
cluster, ECU, EFI system, main harness, lights, accessories and power steering. The relays assist with component operation like the
cooling fan, fuel pump, EFI system, drive system and electronic power steering. A separate 20-amp circuit breaker protects the fan
motor circuit.
