Polaris Ranger RZR 800 User Manual

5.27
BODY / STEERING / SUSPENSION
5
Steering Wheel Removal (EPS Models)
1. Remove the upper steering shaft, pivot tube and steering
wheel as an assembly before attempting to remove the
steering wheel. Refer to “Upper Steering Shaft Removal
(EPS Models)”.
2. Remove the steering wheel cap.
3. Loosen the nut and back it half way off the steering shaft.
4. Place the assembly in a vise.
5. Using a large bronze drift and hammer, strike the steering
shaft nut to pop the steering wheel off the shaft taper.
6. Once the steering wheel pops loose, completely remove the
nut and lift the steering wheel off the shaft.
Power Steering Unit Removal
1. Remove the upper steering shaft, pivot tube and steering
wheel from the vehicle as an assembly. Refer to “Upper
Steering Shaft Removal (EPS Models)”.
2. Disconnect the (2) electrical harnesses from the power
steering unit.
CAUTION
Striking the steering wheel or steering shaft
while installed in the vehicle can permanently
damage the EPS unit and cause a
Power Steering Fault.
CAUTION
Striking the steering wheel or steering shaft
while installed in the vehicle can permanently
damage the EPS unit and cause a
Power Steering Fault.
Remove
Remove
