7.52
FINAL DRIVE
8. Carefully install the shift yoke assembly into the gearcase.
9. Install the shift yoke assembly with the shift return springs
(C), facing down in the housing.
10. Install the lock pin assembly and tighten.
11. Install the differential assembly into the gearcase housing
and install a new lightly greased O-ring onto the cover.
12. Assemble the gearcase halves and install the bolts that
secure the cover to the housing. Torque the bolts in a criss-
cross pattern to 23-27 ft. lbs. (31-37 Nm).
13. If previously removed, install the differential solenoid.
Torque the solenoid to 30-40 ft. lbs. (41-54 Nm).
C
O-Ring
23-27 ft. lbs.
(31-37 Nm)
30-40 ft. lbs.
(41-54 Nm)
