Page #371 background image
10.23
ELECTRICAL
10
REAR DIFF SOLENOID RELAY (INT’L) provides power
to the following system:
• Rear Differential Solenoid
REAR DIFF SOLENOID RELAY (INT’L)
C
OLOR
F
UNCTION
Red / Dark Green
10-Amp fuse protected 12 Vdc battery
voltage.
Dark Green / White ECU input to enable relay.
Brown Relay coil ground.
Red
Relay switched power to operate the
Rear Diff Solenoid.
Blue
Ground to energize the Rear Diff
Solenoid.
