1 - 8
Figure 1-4 shows the components within the viewfinder which direct the image
from the front window to the eyepiece. There are six plastic lenses, four mirrors, a
mask and a black border which define the image and clearly show the extent of the
image which will be captured on the film frame, and a plastic wedge which aligns
the image relative to the eyepiece.
Figure 1-4. Viewfinder Components
EYE CUP
RETAINER
YOKE
OBJECTIVE
LENS
FIELD
LENS
NEGATIVE
LENS 2
VIEWFINDER
PUPIL MASK
NEGATIVE
LENS 1
RELAY LENS
VIEWFINDER
IMAGE MASK
FILLER
PLATE
SPRING
VIEWFINDER BASE
EYE LENS
EYE LENS
TURRET
FILLER PLATE
TURRET
HOUSING
SPRING
VIEWFINDER
COVER
EYE CUP
