2. Testing and Adjustments
STAR Tester
Basic Operation
The STAR Tester (Figure 2-1) is an upgrade of the Model 12650-2 (for 600-
Series and other cameras. This model (12650-3) permits testing the ProCam and
Spectra System Cameras for seven different exposure and timing related operating
characteristics, as well as 600-Series and other cameras.
Except for a few name changes of Selector Switch positions, the model 12650-3
STAR Tester is outwardly identical to the earlier model 12650-2 STAR Tester.
Figure 2-1. STAR Tester
2
4
5
6
7
8
9
10
13
16
17
19
18
15
14 11
12
1
3
