1 - 15
Figure 1-13. Hybrid Light and Distance Measurements
ProCam Light Measurements
As in the Spectra system, a brightness detect reading is taken by the
exposure circuitry during Preview. Scene brightness is measured at this
time and is categorized into:
High Brightness - above 12 cd/ft
2
or,
Low Brightness - below 12 cd/ft
2
This brightness information is used to determine strobe firing timing. A
second brightness detect reading was added in the upgrade. During this
second reading, the exposure system categorizes scene brightness into:
High Brightness: > 24 cd/ft
2
Mid Brightness: 8 to 24 cd/ft2
Low Brightness: < 8 cd/ft
2
TRANSDUCER PROVIDES
DISTANCE INFORMATION
DUAL PHOTODIODES
PROVIDE LIGHT INFORMATION
