Customizing Your SoundPoint IP 335 Phone
2 - 9
The phone will restart to set the new directory search mode if you pressed
the Yes soft key.
Muting the Microphone
During a call, press . The Message Waiting Indicator turns red and a
microphone on the screen indicates that the other party (or parties) cannot
hear you.
Microphone Mute applies to all modes: Handset, Headset, and Hands-free
Speakerphone. You can still hear all other parties while mute is enabled.
To turn off Microphone Mute, press again.
Adjusting the Volume
Press to adjust receiver volume during a call. Pressing
these keys in the idle state adjusts the ringer volume.
Managing Call Lists
A list of up to four current calls is maintained. You can scroll through this list
using the and . Calls are ordered using the following priorities:
active, alerting, then held. Calls with the same priorities are ordered oldest
first. If there are no current calls, this list is empty.
Local lists of incoming—both missed and received calls—and outgoing (also
known as placed) calls is maintained by the phone (up to 99 for each list). The
initial view of both lists shows the list title and the first two calls in the list,
where the first call is displayed in reverse video to indicate that it is currently
selected. A symbol to indicate whether the call was answered or
missed is shown for each entry in the incoming list.
Press the Callers soft key to view the Received Calls list (shown in the
following figure).
Note
Depending on the size of your local contact directory, the reconfiguration may take
a few minutes.
Note
To conform to regulatory requirements, handset and headset volume will return to a
preset level after each call, but your system administrator can change this.
Hands-free Speakerphone volume settings will be maintained across calls.

Table of Contents

Other manuals for Polycom SoundPoint IP 335

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Polycom SoundPoint IP 335 and is the answer not in the manual?

Polycom SoundPoint IP 335 Specifications

Operating Environment IconOperating Environment
operating temperature0 to 40°C
operating relative humidity5% to 95%, non-condensing
storage temperature-40 to +70°C
Power IconPower
power over ethernetIEEE 802.3af Class2
external AC adapter voltage24V DC
external AC adapter current500mA
Weight and Dimensions IconWeight and Dimensions
phone weight0.625 kg
unit box dimensions25 cm x 10.5 cm x 29.5 cm
unit box weight1.49 kg
size17 cm x 14.5 cm x 17.5 cm
