User Guide for the Polycom SoundStation IP 6000 Phone
1 - 4
The following figure shows how to connect your phone to the network using
optional AC power.
To connect the phone using AC power:
1. Connect one end of the 25-foot Network Cable to the LAN jack on the
phone.
2. Connect the other end of the 25-foot Network Cable to the
Power Insertion Cable.
3. Connect the Power Insertion Cable to an available LAN port on the wall
or hub/switch device port.
4. Connect the Power Adapter to the Power Insertion Cable.
5. Connect the Power Adapter (with the attached Regional Power Cord) to
the wall outlet.
Connecting Optional Extension Microphones to Your Conference Phone
You can connect extension microphones to expand the room coverage of your
conference phone.
To connect extension microphones to your phone, you will need the optional
External Microphone Kit, which contains two extension microphones.
2
3
4
5
1
Power Adapter
Power Insertion Cable
25-foot Network Cable

Polycom SoundStation IP 6000 Specifications

General

Network Interface	10/100 Ethernet
Power over Ethernet (PoE)	Yes, IEEE 802.3af
SIP Protocol Support	Yes
Connectivity Technology	Wired
Echo Cancellation	Yes
Noise Reduction	Yes
Speakerphone	Full-duplex
Microphones	3 cardioid microphones
Microphone Type	Cardioid
Display	Backlit LCD display
Audio Technology	HD Voice, Acoustic Clarity Technology
Protocols	SIP
Network Ports	1
Power Source	PoE or optional AC adapter
Weight	1.75 lbs
Compliance	FCC
Dimensions	14.5 x 12.25 x 2.5 in (36.8 x 31.1 x 6.4 cm)
