Polycom SoundStation IP 6000 User Manual

User Guide for the Polycom SoundStation IP 6000 Phone
3 - 4
Answering Calls
To answer a call:
>> Press or the Answer soft key.
The three LEDs flash green when the phone rings.
To answer a call on a shared line:
1. Answer the incoming call.
2. Press the Hold soft key.
Anyone on another phone configured to use the same shared line can take the
call by selecting the call on their phone screen.
Ending Active Calls
To end a call:
>> Press or the End Call soft key.
Muting the Microphone
To mute the microphone:
>> During a call, press .
The three console LEDs glow red to indicate that the other party (or parties)
cannot hear you. You can still hear all other parties while Mute is enabled.
To turn off the Mute feature, press again.
Note
To ignore Incoming calls, press the Reject soft key (for private lines) or the
Silence soft key (for shared lines). To prevent your phone from ringing, enable the
Do Not Disturb feature (see Using Do Not Disturb on page 3-14).
You can forward incoming calls by pressing the Forward soft key (see
Forwarding Calls Dynamically on page 3-13).
If you set up your phone with a silent ring, press the Answer soft key to answer the
call.
Note
You cannot end a call that is on hold until you resume the call. To end a held call,
press the Resume soft key, and then end the call.

Polycom SoundStation IP 6000 Specifications

General

Network Interface	10/100 Ethernet
Power over Ethernet (PoE)	Yes, IEEE 802.3af
SIP Protocol Support	Yes
Connectivity Technology	Wired
Echo Cancellation	Yes
Noise Reduction	Yes
Speakerphone	Full-duplex
Microphones	3 cardioid microphones
Microphone Type	Cardioid
Display	Backlit LCD display
Audio Technology	HD Voice, Acoustic Clarity Technology
Protocols	SIP
Network Ports	1
Power Source	PoE or optional AC adapter
Weight	1.75 lbs
Compliance	FCC
Dimensions	14.5 x 12.25 x 2.5 in (36.8 x 31.1 x 6.4 cm)
