3-19
3 First Steps
Unfold the
workplate
To have more legroom when working on the system, you can move the work
plate up to 12cm forwards. To do so, proceed as follows:
1. Fold in the screen.
CAUTION!
Risk of tilting caused by mishandling! Fold in the screen before unfixing the locking
hooks and moving the workplate. Otherwise the screen loads the workplate one-sided and
the work plate can tilt.
2. Loosen the wing screws that fix the work plate and unfix the locking
hooks.
3. Move the work plate into the front position.
4. Fix the locking hooks and tighten the wing screws again.
5. Fold out the screen again.
If you order a system cabinet retrospectively, you will have to install all the
components in the system cabinet yourself. Orient yourself towards
FIGURE
3.13 and proceed as follows:
1. Carefully unscrew the housing feet of all the individual system
components and keep them with the screws in a safe place.
2. Place the PC at the bottom.
3. Insert the front-end above the PC.
4. Fasten all the front panels using the screws provided.
5. Mount the monitor as described in the assembly instructions provided by
the manufacturer of the monitor arm.
6. Carry out the cabling of the system components as described in
SECTION
3.5.
