A-19
A Optional Accessories
A.5.4.6 Dimensions
Vertical Test Stand
Figure A.12: Dimensions of the vertical test stand with scanning head (Dimensions not specified are given in
mm.)
Beam
Movement 180 -530
Beam
203.20
437.6
732.5 - 1082.5
439.30
72.5
Warning!
Do not bring any parts of the body
or mechanicalparts into this area
while the telescope drive is moving.
161
200
220
43
=
=
=
=
43
161
250
254
290
