PDR-7000 Operation Manual
3.8 Calling Up Measurement Data.
The PDR-7000 stores the last 50 measurement data. It is possible to display the
data.
1. Display the Recall Data screen.
Press
Press
2. Select a desired data.
Press the far left button of the desired data.
the whole data is read.
3.9 Link Off Function
This function prevents auxiliary lenses or mode (S/C/A) from being switched
automatically when changing a chart. See “3.12 Parameter Settings”.
3.10 Programming
The PDR-7000 has ten programs of Fixed(A, B) and User(A ~ H).
The standard program has already been written in Fixed Programs A and B as
factory setting.
User Programs(A~H) are empty. All programs (Fixed(A,B) and User(A~H).) are
programmable.
See “2.5 Standard Program Refraction” for the contents of Fixed Program A.
See “7.4 Standard Program” for the contents of Fixed Program B.
- 45 -
