PDR-7000 Operation Manual
• Data field (SPH, CYL, AXIS, VA)
• Eye to be measured (R, L, BIN)
• Cross cylinder test
• Fog amount
• Data to be entered (Unaided to Final)
• Auxiliary lenses
• With or without beep sounds
• Whether the near point lamp lights up or goes out
NOTE
- It is impossible to select the cross cylinder setting between Flipped and Auto. Set
the lens type with the Cross cylinder (XC) test parameter.
- It is possible to add the fog function with both eyes open. Set the fog according to
“3.5 Fog Function with Both Eyes Open”. The setting is programmed the same as
other auxiliary lenses.
7. When the steps on the screen are programmed, go to the next page.
Press on the middle of right of the screen.
When all steps are programmed, press [X] button.
8. Repeat Steps 4 and 6 until the desired charts are programmed in the
presentation order.
It is possible to store up to 30 steps.
9. Exit from programming mode.
Press [X] until the screen returns to the normal measurement screen.
3.10.2 Operating programs
The charts are presented in the programmed order.
1. Select the program to be used with +
2. Start the program.
Press
The first chart in the program is presented and the refractor head is set as
programmed.
3. Present the next chart.
Press . Each time the key is pressed, the chart is presented in the programmed
order and the refractor is set as programmed.
+ Returns to the previous chart
- 47 -
