PDR-7000 Operation Manual
1.3 Configuration
1.3.1 Refractor head
1. Measuring window
3. VD chec k window
2. Near point lamp
4. Forehead rest detection lamp
5. Forehead rest knob
6. Level
7. Near point c ard
8. Near point rod
9. Level adjustment knob
Operator’s side
Patient’s side
10. Forehead rest
11. Face shield
- 2 -
