PDR-7000 Operation Manual
When they are not aligned, correct them as follows:
Appearance of chart Phoria Correction
1) The top frame is shifted
to the left.
Right eye
hyperphoria
Press . Turn the dial counterclockwise until
the top and bottom frames are aligned.
2) The top frame is shifted
to the right.
Left eye
hyperphoria
Press . Turn the dial clockwise until the top
and bottom frames are aligned.
Use or instead of the dial for fine adjustment.
- 75 -
