Power Electronics SD450 Series User Manual

SD450 - DEVICENET POWER ELECTRONICS
46
ADDRESS LIST
Address Range
16 bit 10 bit
Screen Description
Default
value
Option Values
9219 37401
FU1-25
DCBr Frq
DC brake starting frequency 500
10 –
6000
921A 37402
FU1-26
DCBr time
Time of DC current application 10 0 – 600
921B 37403
FU1-27
DCBr value
DC current level applied for DC
brake
50 0 – 200
No
921C 37404
FU1-28
Safety Stop
Motor stopped at safety
conditions from power supply
loss
0
Yes
0 – 1
921D 37405
FU1-29
Line Freq
Line frequency value 5000
4000 –
12000
921E 37406
FU1-30
Max Freq
Maximum output frequency of
the inverter
5000
4000 –
12000
921F 37407
FU1-31
Base Freq
Output frequency for motor
rated voltage
5000
3000 –
12000
9220 37408
FU1-32
Start Freq
Start frequency 50 1 - 1000
No
9221 37409
FU1-33
Freq limit
Frequency limits selection 0
Yes
0 – 1
9222 37410
FU1-34
F-limit Lo
Low frequency limit 50
0 – FU1-
35
9223 37411
FU1-35
F-limit Hi
High frequency limit 50000
FU1-34 –
FU1-30
Linear
Square
9228 37416
FU1-40
V/F pattern
Relation factor between voltage
and frequency applied to the
motor
0
User V/F
0 – 2
9229 37417
FU1-41
User Freq 1
Frequency 1 (User V/F pattern)
1500
0 – FU1-
30
922A 37418
FU1-42
User volt 1
Voltage 1 (User V/F pattern) 25 0 – 100
922B 37419
FU1-43
User Freq 2
Frequency 2 (User V/F pattern) 3000
0 – FU1-
30
922C 37420
FU1-44
User volt 2
Voltage 2 (User V/F pattern) 50 0 – 100
922D 37421
FU1-45
User Freq 3
Frequency 3 (User V/F pattern)
4500
0 – FU1-
30
922E 37422
FU1-46
User volt 3
Voltage 3 (User V/F pattern) 75 0 – 100
922F 37423
FU1-47
User Freq 4
Frequency 4 (User V/F pattern)
5000
0 – FU1-
30
9230 37424
FU1-48
User volt 4
Voltage 4 (User V/F pattern) 100 0 – 100
