POWER ELECTRONICS SD450 - DEVICENET
ADDRESS LIST
47
ENGLISH
Address Range
16 bit 10 bit
Screen Description
Default
value
Option Values
9231 37425
FU1-49
VAC 400.4V
Input voltage setting 910
730 –
1150
9232 37426
FU1-50
Motor Volt
Motor rated voltage 400 0 – 600
None
Manual
9233 37427
FU1-51
Energy save
Energy save level
enabled/disabled
0
Auto
0 – 2
9234 37428
FU1-52
Manual save%
Energy save level 0 0 – 30
9236 37430
FU1-54
KiloWattHour
Displaying of Mega and Kilo
watts
- -
9237 37431
FU1-55
Inv. Temp.
Inverter temperature 25 0 – 160
9238 37432
FU1-56
Motor Temp.
Motor temperature 25 0 – 160
No
923C 37436
FU1-60
ETH select
Electronic thermal protection 1
Yes
0 – 1
923D 37437
FU1-61
ETH 1min
Electronic thermal protection
level for 1 minute
150
FU1-62 –
200
923E 37438
FU1-62
ETH cont
Electronic thermal protection
level for continuous
105
50 –
FU1-61
(max.
150)
Self-cool
923F 37439
FU1-63
Motor type
Motor cooling mode 0
Forced-
cool
0 – 1
9240 37440
FU1-64
OL level
Overload warning level 110 30 – 110
9241 37441
FU1-65
OL time
Overload warning time 100 0 – 300
No
9242 37442
FU1-66
OLT select
Overload trip selection 1
Yes
0 – 1
9243 37443
FU1-67
OLT level
Overload trip level 120 30 – 150
9244 37444
FU1-68
OLT time
Overload trip time 600 0 – 600
9245 37445
FU1-69
Trip select
Input / output phase loss
protection
4 (Bit
setting)
0 – 7 (Bit
setting)
9246 37446
FU1-70
Stall prev.
Stall prevention mode
0 (Bit
setting)
0 – 7 (Bit
setting)
9247 37447
FU1-71
Stall level
Limitation current level 100 30 – 150
