Precor Experience Series User Manual

3. Remove the left and right Stairarms from the respective input Crank Spindle, see "Stair-
arm Input Crank Removal" on page199. Repeat procedure for the left and right Stair-
arms.
4. Remove the left and right Stairarm wheels from the ramp. Roll the Stairarm wheel down
and off the back of the ramp track. Carefully lay the Stairarm onto the floor.
5. Remove the left and right 3/4" (19 mm) ramp pivot bolts, flat washers, and spacers.
6. Then carefully lift the ramp up and place a jack stand (or blocking material) to securely
hold the ramp above the Ramp Pivot cover . Note that the ramp can move side-to-
side when removed from the weldment pivot hinge bracket.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 97
6 Replacement Procedures
Covers and Panels Replacement
