P80 and P82 touchscreen consoles
The P80 and P82 consoles use the touch sensitive touchscreen controls to select items and
navigate the service menus. Only one hardkey "Pause" is used to stop a running diagnostic
test.
Follow the on-screen prompts to run the diagnostic tests.
CONSOLE KEY FUNCTION/DESCRIPTION
Touchscreen controls There are various touch sensitive softkey controls (OK.
START, STOP, BACK, etc.) and icon controls (image
boxes, buttons, etc.) used to control and operate the con-
sole. Make selection by touching the softkey control or
icon.
Scroll Up/Dwn Use your finger to swipe the touchscreen up or down to
scroll through menu items. Some menus provide a vertical
scroll bar on the screen right side to scroll Up/Dwn.
BACK softkey • Use the touchscreen BACK softkey to return to the pre-
vious menu display.
• Continue selecting the BACK softkey to exit the service
software.
PAUSE hardkey Stop a running diagnostic test.
P62 touchscreen consoles
The P62 console uses a combination of touchscreen softkeys/icons and keypad hardkeys to
select and navigate thru the service and diagnostics menus. The P62 uses the BACK keypad
button to return to the previous menu and the PAUSE hardkey to stop a running diagnostic
test.
Follow the on-screen prompts run the diagnostic tests.
CONSOLE KEY FUNCTION/DESCRIPTION
Touchscreen con-
trols
There are various touch sensitive softkey controls (OK. START,
STOP, BACK, etc.) and icon controls (image boxes, buttons, etc.)
used to control and operate the console. Make selection by touching
the softkey control or icon.
Scroll Up/Dwn Use your finger to select while swiping your finger Up/Dwn to scroll
through menu lists. Some menus provide an on-screen scroll bar to
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 26
4 Standard Service Menus
Navigating the Service Menus
