Lift Interface Plate Cover Replacement
Lift Interface Plate Cover Replacement
ID Description
Lift Interface Plate Cover
Removal Instructions
1.
Remove the Lift Front cover , see "Lift Front Cover Replacement" on pageî72.
2.
Remove the two #3 Phillips screws and remove the Lift Interface Plate cover .
Retain part(s) and/or fastener(s) for installation.
Installation Instructions
1.
Reinstall the Lift Interface Plate cover , snap the lower tabs in place and align the two
fastener bolt holes. Secure with two #3 Phillips screws.
2.
Reinstall the Lift Front cover cover , see "Lift Front Cover Replacement" on pageî72.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 76
6 Replacement Procedures
Covers and Panels Replacement
