Drive Access Panel Replacement
Drive Access Panel Replacement
ID Description
Drive Access Panel
Removal Instructions
1. Use a #3 Phillips screwdriver to remove the two fasteners located at the bottom of the
Drive Access panel . Slide the Drive Access panel downward and upward away
from the Drive Housing covers to remove. Retain part(s) and/or fastener(s) for install-
ation.
Installation Instructions
1.
Slide the top of the Drive Access panel under the top lip of the Drive Housing covers
and then press down on the bottom edge of the Drive Access panel to snap in place.
2. Secure Drive Access panel using the two # 3 Phillips screws.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 83
6 Replacement Procedures
Covers and Panels Replacement
