Precor Experience Series - Drive Housing Covers Replacement

Drive Housing Covers Replacement
Drive Housing Covers Replacement
Use this procedure to remove both the left and right drive covers.
Tools
l 5/16" socket drive l Torx T25 screwdriver
l #2 & #3 Phillips screw driver l 0.047" external retaining ring pliers
Exploded View
ID Description
Transition Cover
Drive Cover - Right
Drive Cover - Left
Removal Instructions
Remove the left and right Stairarms from the Crank Spindle:
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
