1.
Set the bottom of the Lift Front cover onto the lift interface plate and right/left Lift
Side covers ( & ) making sure the clips fit over the top edge of the covers. Then
press the front cover into onto the right and left Lift Side covers making sure the cover
tabs lock in place.
2.
Position the Lift Top cover into position on top of the Accessory Tray and press to
lock tabs in place.
3.
Position the Goose Neck cover into position on top of the Lift Front cover and
press to lock tabs in place.
4.
Reinstall the Goose Neck Gasket around the goose neck weldment and press to
snap in place. Start at the front and alternately work your way around the weldment
tube finishing at the back.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 75
6 Replacement Procedures
Covers and Panels Replacement
